Truck Air filter making machine car air filter making machine

FOB Reference Price:Get Latest Price
US $3,500-3,680 / Sets | 1 Set/Sets Truck Air filter making machine car air filter making machine (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Hebei, China (Mainland)
Brand Name:
Leiman
Model Number:
LM04A
After-sales Service Provided:
No overseas service provided
Product name:
Truck Air filter making machine car air filter making machine
Product type:
Pleating machine
Voltage:
380v
Power(w):
1.5kw
Dimension(L*W*H):
1800mm*1180mm*900mm
Weight:
500kg
Certification:
CE
Type:
Air Filter Pleating machine
Usage:
filter product
Function:
Pleating machine
Supply Ability
Supply Ability:
25 Set/Sets per Month Truck Air filter making machine car air filter making machine
Packaging & Delivery
Packaging Details
Wooden box
Truck Air filter making machine car air filter making machine
Port
Tianjin port
Lead Time :
7-20days

Truck Air filter making machine car air filter making machine

Air filter making machine truck and car air filter making machine

Truck Air filter making machine car air filter making machineTruck Air filter making machine car air filter making machine

First, the major component of the equipment

1, paper planes automatically
2, to lose paper cut
3, printer
4, automatic counters
5, paper folding machine

Second, technical parameters
1, to cut lose paper: LMCZ55-1050-
(1) feeding speed: 0.5m/min ~ 12m/min adjustable
(2) Adjustable Paper Width: 32 ~ 1100mm
(3) supply voltage: 220V/50HZ
(4) Motor Power: 0.75kw
(5) Working pressure: 0.6MPa
(6) Machine Weight: 350kg
(7) Overall dimension: 1500 * 1300 * 1100mm
2, printer: LMCZ55-1050-
(1) Print width: 1050mm
(2) printed from the adjustable range: 8 ~ 55mm
(3) supply voltage: 220V/50Hz
(4) motor power: 1.5kw
(5) Machine Weight: 300kg
(6) Overall dimension: 1550 * 520 * 1100mm
3, folding machine: LMCZ55-1050-
(1) product maximum width: 1050mm
(2) adjustable folding high range: 8 ~ 55mm
(3) Folding speed: 0 ~ 200 packs / min stepless adjustable
(4) Supply Voltage: 380V/50HZ
(5) Motor Power: 1.1kw
(6) warm-up power: 4kw
(7) Temperature range: room temperature ~ 200
(8) Working pressure: 0.6MPa
(9) Machine Weight: 650kg
(10) Overall dimension: 1670 * 1720 * 1240mm
