Made in China spiral tube making machine ducting machine

FOB Reference Price:Get Latest Price
US $6,800-8,000 / Unit | 1 Unit/Units Made in China spiral tube making machine ducting machine (Min. Order)
Supply Ability:
25 Unit/Units per Month Made in China spiral tube making machine ducting machine
Port:
Tianjin Port
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Product Type:
Made in China spiral tube making machine ducting machine
Processing Type:
Made in China spiral tube making machine ducting machine
Place of Origin:
Hebei, China (Mainland)
Brand Name:
PLJY109-500
Model Number:
LM 04A
Voltage:
380 V
Power(W):
2.2kW
Dimension(L*W*H):
1500*1180*2000mm
Weight:
550kg
Certification:
CE
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Product Name:
Made in China spiral tube making machine ducting machine
Diamond mesh width:
109mm
Product capability:
10-20pcs/min
Roll diameter:
80-500mm
thickness steel plate:
0.25-0.4mm
motor Power:
2.2kW
Power supply:
380v/50hz
Working air pressure:
0.6mpa
M/C weight:
550kg
size:
1500*1180*2000mm
Packaging & Delivery
Packaging Details
wooden box
Made in China spiral tube making machine ducting machine
Delivery Time
Shipped in 7 days after payment

Made in China spiral tube making machine ducting machine

General description



This machine is suitable for coiling machine in automotive air filter and

external protective net diamond.



Specification



1,Diamond mesh width :109mm
2,Product capacity:10-20pcs/min
3,Roll diameter:80-500mm
4,The thickness of the steel plate rolling:0.25-0.4mm
5,motor Power:2.2kW
6,Power supply: 380v/50hz
7,Working air pressure:0.6mpa
8,M/C weight:550kg
9,M/C size: 1500×1180×2000mm(L×W×H)
10,The size of the machine:740×700×1100mm(L×W×H)





Computer control and simple operation Filter Paper Rotary pleating machine

1,Consists


1,Auto paper de-coiler
2,Paper Pre-slitting machine
3,Pre-heating device before pleating
4,Auto counter
5,Water steam device
6,Rollers marking machine
7,Roller and gear collecting device
8,Pleated paper heat forming and conveyer device


2, Specification
1,Product capability:0~35m/min
2,Max.width:600mm
3,Min.width:30mm
4,Max.pleat height:50mm
5,Min.pleat height:10mm
6,Customize the rollers sizes
7,Temp.control: normal temp.~300oC
8,Main power:12kw
9,Working air pressure:0.6MPa
10,Power supply:380V/50Hz
11,M/C weight:750kg
12,M/C dimension:4135×1190×1170mm(L×W×H)
3,Features
1,The pre-slitter uses pneumatic cutting round knife, which is adjusted simply and pressed evenly.
2,This machine equips the pre-heating and water steam device, to prevent the paper breaking when roller marking.
3,This machine equips the gear collecting system, so to faster the pleating speed and well pleated the paper.
4, The rollers can be made with bubbled type or the pleat-lock type, which is used to maintenance the certain distance between two pleats.
5,This high automatic machine has the process of the process of the auto count marking,pleating,pre-heating and forming.
6,This machine is computer control and simple operation.
4, Applications
This machine is used for pleating and forming the HDAF filter element.







Our Services

We can also provide some other filter accessory: expended metal mesh, perforated metal mesh ,plastic frame ,PU mould ,all kinds of end covers ,and glue used for making filters .we can provide you the best price .
